Programming Q Parameters | Additional functions

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

391

Printing messages

You can also use the function FN16: F-PRINT to print any

messages on a connected printer.

Further information: "Printer", page 107

In order for the messages to be sent to the printer, you must

enter Printer:\ as the name of the log file and then enter the

corresponding file name.

The control saves the file in the PRINTER: path until the file is

printed.

Example

96 FN 16: F-PRINT TNC:\MASKE\MASKE1.A/PRINTER:\DRUCK1
