HEIDENHAIN TNC 620 Programming Station

Pallets | Pallet management (option number 22)
Column Meaning Field type
LOCATION Location of the pallet
The entry MA indicates that there is a pallet or fixture
in the working space of the machine and can be
machined. Press the ENT key to enter MA. Press the
NO ENT key to remove the entry and thus suppress
machining.
Optional field
If the column exists, the entry is
mandatory.
LOCK Line locked
Using an * you can exclude the line of the pallet table
from processing. Press the ENT key to identify the
line with the entry *. Press the NO ENT key to cancel
the lock. You can lock the execution for individual NC
programs, fixtures or entire pallets. Unlocked lines (e.g.
PGM) in a locked pallet are also not executed.
Optional field
PALPRES Number of the pallet preset Optional field
This entry is only required if pallet
presets are used.
W-STATUS Execution status Optional field
This entry is only required for tool-
oriented machining.
METHOD Machining method Optional field
This entry is only required for tool-
oriented machining.
CTID ID for mid-program startup Optional field
This entry is only required for tool-
oriented machining.
SP-X, SP-Y,
SP-Z
Clearance height in the linear axes X, Y, and Z Optional field
SP-A, SP-B,
SP-C
Clearance height in the rotary axes A, B, and C Optional field
SP-U, SP-V,
SP-W
Clearance height in the parallel axes U, V, and W Optional field
DOC Comment Optional field
COUNT Number of operations
For rows of the PAL type: Current actual value for the
pallet counter nominal value defined in the TARGET
column.
For rows of the PGM type: Value indicating by how
much the pallet counter actual value will be increment-
ed after the execution of the NC program.
optional field
TARGET Total number of operations
Nominal value for the pallet counter in rows of the PAL
type
The control repeats the NC programs of this pallet until
the nominal value has been reached.
optional field
