Operating the Touchscreen | Gestures

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

129

Operating the simulation

The control offers touch operation with the following graphics:

Programming graphics in the Programming mode of operation

3-D view in the Test Run operating mode

3-D view in the Program Run Single Block operating mode

3-D view in the Program Run Full Sequence operating mode

Kinematics view

Rotate, zoom or move a graphic

The control supports the following gestures:

Symbol Gesture Function

Double tap Set the graphic to its original size

Drag Rotate the graphic (only 3-D graphics)

Two-finger drag Move graphics

Spread Magnify the graphic

Pinch Reduce the graphic
