Multiple-Axis Machining | Functions for multiple axis machining

534

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

13.1 Functions for multiple axis machining

This chapter summarizes the control functions for multiple axis

machining:

Control function Description Page

PLANE

Define machining in the tilted working plane 535

M116

Feed rate of rotary axes 565

PLANE/M128

Inclined-tool machining 563

FUNCTION TCPM

Define the behavior of the control when positioning the rotary axes

(enhancement of M128)

573

M126

Shortest-path traverse of rotary axes 566

M94

Reduce display value of rotary axes 567

M128

Define the behavior of the control when positioning the rotary axes 568

M138

Selection of tilted axes 571

M144

Calculate machine kinematics 572

LN blocks

Three-dimensional tool compensation 579
