MOD Functions | Setting up data interfaces
19
752
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Set protocol
(protocol no. 106702)
The data transfer protocol controls the data flow of a serial
transmission (comparable to MP5030 of the iTNC 530).
Operating notes:
The BLOCKWISE setting designates a type of data
transfer in which the data is transferred grouped in
blocks.
The BLOCKWISE setting does not correspond to the
data reception in blocks nor to the simultaneous
execution of older contouring controls in blocks. This
function is no longer available for current controls.
Data transmission protocol Selection
Standard data transmission (transmission
line-by-line)
STANDARD
Packet-based data transfer BLOCKWISE
Transmission without protocol (only charac-
ter-by-character)
RAW_DATA
Set data bits
(dataBits no. 106703)
By setting the data bits you define whether a character is
transmitted with 7 or 8 data bits.
Check parity
(parity no. 106704)
The parity bit helps the receiver to detect transmission errors. The
parity bit can be formed in three different ways:
No parity (NONE): There is no error detection
Even parity (EVEN): Here there is an error if the receiver finds
that it has received an odd number of set bits
Odd parity (ODD): Here there is an error if the receiver finds that
it has received an even number of set bits
Set stop bits
(stopBits no. 106705)
The start bit and one or two stop bits enable the receiver
to synchronize each transmitted character during serial data
transmission.
