Tables and overviews | System data
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
Preset from touch probe cycle (probing results)
1 Coordinate Last preset of a manual touch probe cycle, or
last touch point from Cycle 0 (input coordinate
system).
Compensations: length, radius, and center
offset
2 Axis Last preset of a manual touch probe cycle, or
last touch point from Cycle 0 (machine coordi-
nate system, only axes from the active 3-D
kinematics are allowed as index).
Compensation: only center offset
3 Coordinate Result of measurement in the input system
of touch probe Cycles 0 and 1. The measure-
ment result is read out in the form of coordi-
nates. Compensation: only center offset
4 Coordinate Last preset of a manual touch probe cycle,
or last touch point from Cycle 0 (workpiece
coordinate system). The measurement result
is read in the form of coordinates.
Compensation: only center offset
5 Axis Axis values, not compensated
6 Coordinate /
axis
Readout of the measurement results in the
form of coordinates / axis values in the input
system from probing operations.
Compensation: only length
10 - Oriented spindle stop
360
11 - Error status of probing:
0: Probing was successful
–1: Touch point not reached
–2: Touch probe already deflected at the start
of the probing process
15
