Tables and overviews | System data
15
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
TT tool touch probe for tool measurement
1 TT: Touch probe type70
2 TT: Line in the tool touch probe table
71 1/2/3 TT: Touch probe center (REF system)
72 - TT: Touch probe radius
1 TT: Rapid traverse
2 TT: Measuring feed rate with stationary
spindle
75
3 TT: Measuring feed rate with rotating spindle
1 TT: Maximum probing path
2 TT: Safety clearance for linear measurement
3 TT: Safety clearance for radius measurement
76
4 TT: Distance from the lower edge of the cutter
to the upper edge of the stylus
77 - TT: Spindle speed
78 - TT: Probing direction
79 - TT: Activate radio transmission
350
80 - TT: Stop probing movement upon stylus
deflection
570
