Tables and overviews | System data
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
Global Program Settings (GPS)
1 - GPS: Angle of a basic rotation
3 Axis GPS: Mirroring
0 = Not mirrored, 1 = Mirrored
Index: 1 - 6 ( X, Y, Z, A, B, C )
4 Axis GPS: Shift in the modified workpiece coordi-
nate system mW-CS
Index: 1 - 6 ( X, Y, Z, A, B, C )
5 - GPS: Angle of rotation in input coordinate
system I-CS
6 - GPS: Feed rate factor
8 Axis GPS: Handwheel superimpositioning
Maximum value
Index: 1 - 10 ( X, Y, Z, A, B, C, U, V, W, VT )
9 Axis GPS: Value for handwheel superimpositioning
Index: 1 - 10 ( X, Y, Z, A, B, C, U, V, W, VT )
16 Axis GPS: Shift in the workpiece coordinate system
W-CS
Index: 1 - 3 ( X, Y, Z )
332
17 Axis GPS: Axis offset
Index: 4 - 6 ( A, B, C )
TS touch trigger probe
1 Touch probe type:
0: TS120, 1: TS220, 2: TS440,
3: TS630, 4: TS632, 5: TS640,
6: TS444, 7: TS740
50
2 Line in the touch-probe table
51 - Effective length
1 Effective radius of the stylus tip52
2 Rounding radius
1 Center offset (reference axis)53
2 Center offset (minor axis)
54 - Spindle-orientation angle in degrees (center
offset)
1 Rapid traverse
2 Measuring feed rate
55
3 Feed rate for pre-positioning:
FMAX_PROBE or FMAX_MACHINE
1 Maximum measuring range56
2 Set-up clearance
1 Spindle orientation possible
0=No, 1=Yes
350
57
2 Angle of spindle orientation in degrees
15
