System data
number NO....
Index IDX... Description
Read values from or write values to the active datum table
500 Row number Column Read values
Read values from or write values to the preset table (basic transformation)
507 Row number 1-6 Read values
Read axis offsets from or write axis offsets to the preset table
508 Row number 1-9 Read values
Data for pallet machining
1 - Active line
2 - Current pallet number. Read value of the
NAME column of the last PAL-type entry. If the
column is empty or does not contain a numer-
ical value, a value of –1 is returned.
3 - Active row of the pallet table.
4 - Last line of the NC program for the current
pallet.
5 Axis Tool-oriented editing:
Clearance height is programmed:
0 = No, 1 = Yes
Index: 1 - 9 ( X, Y, Z, A, B, C, U, V, W )
6 Axis Tool-oriented editing:
Clearance height
The value is invalid if ID510 NR5 returns the
value 0 with the corresponding IDX.
Index: 1 - 9 ( X, Y, Z, A, B, C, U, V, W )
10 - Row number up to which the pallet table is to
be searched during block scan.
20 - Type of pallet editing?
0 = Workpiece-oriented
1 = Tool oriented
510
21 - Automatic continuation after NC error:
0 = Locked
1 = Active
10 = Abort continuation
11 = Continuation with the rows in the pallet
table that would have been executed next if
not for the NC error
12 = Continuation with the row in the pallet
table in which the NC error arose
13 = Continuation with the next pallet
572
