TRANS DATUM TABLE
Example
13 TRANS DATUM TABLE TABLINE25
You can define a datum shift by selecting a datum number from a
datum table with the TRANS DATUM TABLE function. Proceed as
follows for the definition:
Show the soft-key row with special functions
Press the PROGRAM FUNCTIONS soft key
Select transformations
Select the TRANS DATUM datum shift
Select the TRANS DATUM TABLE datum shift
Enter the line number to be activated by the
control, confirm with the ENT key
If desired, enter the name of the datum table
from which you want to activate the datum
number, and confirm with the ENT key. If you do
not want to define a datum table, confirm with
the NO ENT key
If you have not defined a datum table in the TRANS
DATUM TABLE block, then the control uses the datum
table previously selected with SEL TABLE or the datum
table activated in the Program run, single block or
Program run, full sequence operating mode (status M).
