HEIDENHAIN TNC 620 Programming Station

Tables and overviews | System data
No. IDX Contents Replacement function
1 = Datum table selected
ID 510 Data for pallet machining
7 - Test the insertion of a fixture from the PAL
line
ID 530 Active preset
2 Line Write-protect the line in the active preset
table:
0 = No, 1 = Yes
FN 26 and FN 28: read out the
Locked column
ID 990 Approach behavior
2 10 0 = No execution in block scan
1 = Execution in block scan
ID 992 NR 10 / NR 11
3 Q parameters Number of axes that are programmed in the
selected datum table
ID 1000 Machine parameter
MP number MP index Value of the machine parameter CfgRead
ID 1010 Machine parameter is defined
MP number MP index 0 = Machine parameter does not exist
1 = Machine parameter exists
CfgRead
1)
Function or table column no longer exists
2)
Use FN 26 and FN 28 or SQL to read out the table cell
15
HEIDENHAIN | TNC620 | Klartext Programming User's Manual | 01/2022
589
