Tables and overviews | System data
No. IDX Contents Replacement function
33 Tool no. Thread pitch (Pitch) ID 50 NR 40
ID 51 Data from the pocket table
6 Pocket no. Tool type
2)
7 Pocket no. P1
2)
8 Pocket no. P2
2)
9 Pocket no. P3
2)
10 Pocket no. P4
2)
11 Pocket no. P5
2)
12 Pocket no. Pocket reserved
0 = No, 1 = Yes
2)
13 Pocket no. Box magazine: Pocket above occupied: 0 =
No, 1 = Yes
2)
14 Pocket no. Box magazine: Pocket below occupied: 0 =
No, 1 = Yes
2)
15 Pocket no. Box magazine: Pocket to the left occupied:
0 = No, 1 = Yes
2)
16 Pocket no. Box magazine: Pocket to the right occupied:
0 = No, 1 = Yes
2)
ID 56 File information
1 - Number of lines of the tool table
2 - Number of lines of the active datum table
3 Q parameters Number of active axes that are
programmed in the active datum table
4 - Number of lines in a freely definable table
that has been opened with FN 26: TABOPEN
ID 214 Current contour data
1 - Contour transition mode
2 - Max. linearization error
3 - Mode for M112
4 - Character mode
5 - Mode for M124
1)
6 - Specification for contour pocket machining
7 - Filter for control loop
8 - Tolerance programmed with Cycle 32 ID 30 no. 48
ID 240 Nominal positions in the REF system
8 - ACTUAL position in the REF system
ID 280 Information on M128
2 - Feed rate that was programmed with M128 ID 280 NR 3
ID 290 Switch the kinematics
1 - Line of the active kinematics table SYSSTRING 10290
2 Bit no. Interrogate the bits in MP7500 Cfgread
15
