Tables and Overviews | Functions of the TNC 620 and the iTNC 530 compared
20
818
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Cycle TNC 620 iTNC 530
205 UNIVERSAL PECKING
X, option 19 X
206 TAPPING
X X
207 RIGID TAPPING
X X
208 BORE MILLING
X, option 19 X
209 TAPPING W/ CHIP BRKG
X, option 19 X
210 SLOT RECIP. PLNG (recommended: Cycle 253, option 19)
– X
211 CIRCULAR SLOT (recommended: Cycle 254, option 19)
– X
212 POCKET FINISHING (recommended: Cycle 251, option 19)
– X
213 STUD FINISHING (recommended: Cycle 256, option 19)
– X
214 C. POCKET FINISHING (recommended: Cycle 252, option 19)
– X
215 C. STUD FINISHING (recommended: Cycle 257, option 19)
– X
220 POLAR PATTERN
X, option 19 X
221 CARTESIAN PATTERN
X, option 19 X
225 ENGRAVING
X, option 19 X
230 MULTIPASS MILLING (recommended: Cycle 233, option 19)
– X
231 RULED SURFACE
– X
232 FACE MILLING
X, option 19 X
233 FACE MILLING
X, option 19 –
240 CENTERING
X, option 19 X
241 SINGLE-LIP D.H.DRLNG
X, option 19 X
247 PRESETTING
X X
251 RECTANGULAR POCKET
X, option 19 X
252 CIRCULAR POCKET
X, option 19 X
253 SLOT MILLING
X, option 19 X
254 CIRCULAR SLOT
X, option 19 X
256 RECTANGULAR STUD
X, option 19 X
257 CIRCULAR STUD
X, option 19 X
258 POLYGON STUD
X, option 19 –
262 THREAD MILLING
X, option 19 X
263 THREAD MLLNG/CNTSNKG
X, option 19 X
264 THREAD DRILLNG/MLLNG
X, option 19 X
265 HEL. THREAD DRLG/MLG
X, option 19 X
267 OUTSIDE THREAD MLLNG
X, option 19 X
270 CONTOUR TRAIN DATA for defining the behavior of Cycle 25
X X
275 TROCHOIDAL SLOT
X, option 19 X
276 THREE-D CONT. TRAIN
X, option 19 X
290 INTERPOLATION TURNING
– X, option 96
