Programming Qparameters | Preassigned Q parameters
9
Parameters Tool measurement with the BLUM laser
Q190 Reserved
Q191 Reserved
Q192 Reserved
Q193 Reserved
Parameters Reserved for internal use
Q195 Marker for cycles
Q196 Marker for cycles
Q197 Marker for cycles (machining patterns)
Q198 Number of the last active measuring cycle
Parameter
value
Status of tool measurement with TT
Q199 = 0.0 Tool is within the tolerance.
Q199 = 1.0 Tool is worn (LTOL/RTOL is exceeded)
Q199 = 2.0 Tool is broken (LBREAK/RBREAK is exceeded)
Measurement results from touch probe cycles 14xx
Parameters Measured actual values
Q950 1st position in the main axis
Q951 1st position in the secondary axis
Q952 1st position in the tool axis
Q953 2nd position in the main axis
Q954 2nd position in the secondary axis
Q955 2nd position in the tool axis
Q956 3rd position in the main axis
Q957 3rd position in the secondary axis
Q958 3rd position in the tool axis
Q961 Spatial angle SPA in the WPL-CS
Q962 Spatial angle SPB in the WPL-CS
Q963 Spatial angle SPC in the WPL-CS
Q964 Angle of rotation in the I-CS
Q965 Angle of rotation in the coordinate system of the
rotary table
Q966 First diameter
Q967 Second diameter
