HEIDENHAIN TNC 620 Programming Station User Manual

Programming Q Parameters | Additional functions
10
396
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
36 Tool no. Tool type TYPE
(miller = 0, grinder = 1, ... touch probe = 21)
37 Tool no. Corresponding line in the touch-probe table
38 Tool no. Timestamp of last use
39 Tool no. ACC
40 Tool no. Pitch for thread cycles
Data from the pocket table
1 Pocket
number
Tool number
2 Pocket
number
0 = no special tool
1 = special tool
3 Pocket
number
0 = no fixed pocket
1 = fixed pocket
4 Pocket
number
0 = pocket not locked
1 = pocket locked
51
5 Pocket
number
PLC status
Determine the tool pocket
1 Tool no. Pocket number52
2 Tool no. Tool magazine number
Tool data for T and S strobes
1 T code Tool number
IDX0 = T0 strobe (store tool), IDX1 = T1
strobe (load tool), IDX2 = T2 strobe (prepare
tool)
2 T code Tool index
IDX0 = T0 strobe (store tool), IDX1 = T1
strobe (load tool), IDX2 = T2 strobe (prepare
tool)
57
5 - Spindle speed
IDX0 = T0 strobe (store tool), IDX1 = T1
strobe (load tool), IDX2 = T2 strobe (prepare
tool)
Values programmed in TOOL CALL
1 - Tool number T
2 - Active tool axis
0 = X 1 = Y
2 = Z 6 = U
7 = V 8 = W
3 - Spindle speed S
4 - Oversize for tool length DL
5 - Tool radius oversize DR
60
6 - Automatic TOOL CALL
0 = Yes, 1 = No
