HEIDENHAIN TNC 620 Programming Station

Tables and overviews | System data
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
Data from the pocket table
1 Pocket
number
Tool number
2 Pocket
number
0 = no special tool
1 = special tool
3 Pocket
number
0 = no fixed pocket
1 = fixed pocket
4 Pocket
number
0 = pocket not locked
1 = pocket locked
51
5 Pocket
number
PLC status
Determine the tool pocket
1 Tool no. Pocket number52
2 Tool no. Tool magazine number
File information
1 - Number of lines of the tool table
2 - Number of lines of the active datum table
56
4 - Number of lines in a freely definable table that
has been opened with FN26: TABOPEN
Tool data for T and S strobes
1 T code Tool number
IDX0 = T0 strobe (store tool), IDX1 = T1 strobe
(load tool), IDX2 = T2 strobe (prepare tool)
2 T code Tool index
IDX0 = T0 strobe (store tool), IDX1 = T1 strobe
(load tool), IDX2 = T2 strobe (prepare tool)
57
5 - Spindle speed
IDX0 = T0 strobe (store tool), IDX1 = T1 strobe
(load tool), IDX2 = T2 strobe (prepare tool)
Values programmed in TOOL CALL
1 - Tool number T
2 - Active tool axis
0 = X 1 = Y
2 = Z 6 = U
7 = V 8 = W
3 - Spindle speed S
4 - Oversize for tool length DL
5 - Tool radius oversize DR
6 - Automatic TOOL CALL
0 = Yes, 1 = No
7 - Tool radius oversize DR2
8 - Tool index
60
9 - Active feed rate
15
