HEIDENHAIN TNC 620 Programming Station

Tables and overviews | System data
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
Values programmed in the tool call (system string)
10060 1 - Tool name
Read machine kinematics (system strings)
10290 10 - Symbolic name of the machine kinemat-
ics from Channels/ChannelSettings/CfgKin-
List/kinCompositeModels programmed in
FUNCTION MODE MILL or FUNCTION MODE
TURN.
Traverse range switchover (system string)
10300 1 - Key name of the last active range of traverse
Read current system time (system string)
10321 1 - 16 - 1: DD.MM.YYYY hh:mm:ss
2: D.MM.YYYY h:mm
3: DD.MM.YY hh:mm
4: YYYY-MM-DD hh:mm:ss
5: YYYY-MM-DD hh:mm
6: YYYY-MM-DD h:mm
7: YY-MM-DD h:mm
8: DD.MM.YYYY
9: D.MM.YYYY
10: D.MM.YY
11: YYYY-MM-DD
12: YY-MM-DD
13: hh:mm:ss
14: h:mm:ss
15: h:mm
16: DD.MM.YYYY hh:mm
20: Calender week as per ISO 8601
As an alternative, you can use DAT in
SYSSTR(...) to specify a system time in
seconds that is to be used for formatting.
Read data of touch probes (TS, TT) (system string)
50 - Type of TS probe from TYPE column of the
touch probe table (tchprobe.tp)
70 - Type of TT tool touch probe from CfgTT/type.
10350
73 - Key name of the active tool touch probe TT
from CfgProbes/activeTT.
Read and write data of touch probes (TS, TT) (system string)
10350 74 - Serial number of the active tool touch probe
TT from CfgProbes/activeTT.
Read the data for pallet machining (system string)
1 - Pallet name10510
2 - Path of the selected pallet table.
Read version ID of the NC software (system string)
10630 10 - The string corresponds to the format of
the version ID shown, e.g. 340590 09 or
817601 05 SP1.
15
