First Steps with the TNC 620 | Programming the first part

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Recommended program layout for simple cycle programs

Example

0 BEGIN PGM BSBCYC MM

1 BLK FORM 0.1 Z X... Y... Z...

2 BLK FORM 0.2 X... Y... Z...

3 TOOL CALL 5 Z S5000

4 L Z+250 R0 FMAX

5 PATTERN DEF POS1( X... Y... Z... ) ...

6 CYCL DEF...

7 CYCL CALL PAT FMAX M13

8 L Z+250 R0 FMAX M2

9 END PGM BSBCYC MM

1 Call tool, define tool axis

2 Retract the tool

3 Define the machining positions

4 Define the fixed cycle

5 Call the cycle, switch on the spindle/coolant

6 Retract the tool, end program
