Hiwin D1 - Page 236

LCD Display D1 Servo Drive User Manual
7-20 HIWIN MIKROSYSTEM CORP.
MD20UE01-2109
LCD
No.
Name
Definition
Unit
Default Value
Max.
Min.
217
#
LCD.buff_inv
Invert buffered encoder output.
0: Do not invert.
1: Invert.
-
0
1
0
218
#
LCD.emu_or_b
uff
Switch between buffered encoder
output and emulated encoder
output
0: Buffered encoder output
1: Emulated encoder output
-
0
1
0
221
#
LCD.I1_inv
Invert input I1.
0: Do not invert.
1: Invert.
-
0
1
0
222
#
LCD.I2_inv
Invert input I2.
0: Do not invert.
1: Invert.
-
0
1
0
223
#
LCD.I3_inv
Invert input I3.
0: Do not invert.
1: Invert.
-
0
1
0
224
#
LCD.I4_inv
Invert input I4.
0: Do not invert.
1: Invert.
-
0
1
0
225
#
LCD.I5_inv
Invert input I5.
0: Do not invert.
1: Invert.
-
0
1
0
226
#
LCD.I6_inv
Invert input I6.
0: Do not invert.
1: Invert.
-
0
1
0
229
#
LCD.I9_inv
Invert input I9.
0: Do not invert.
1: Invert.
-
0
1
0
230
#
LCD.I10_inv
Invert input I10.
0: Do not invert.
1: Invert.
-
0
1
0
231
#
LCD.I11_inv
Invert input I11.
0: Do not invert.
1: Invert.
-
0
1
0
232
#
LCD.I12_inv
Invert input I12.
0: Do not invert.
1: Invert.
-
0
1
0
261
#
LCD.O1_inv
Invert output O1.
0: Do not invert.
1: Invert.
-
0
1
0
262
#
LCD.O2_inv
Invert output O2.
0: Do not invert.
1: Invert.
-
0
1
0
263
#
LCD.O3_inv
Invert output O3
0: Do not invert.
1: Invert.
-
0
1
0
264
#
LCD.O4_inv
Invert output O4.
0: Do not invert.
1: Invert.
-
1
1
0
300
#
LCD.pullA_dow
n_up
Group A-Switch between high
level and low level (Pull A).
0: Higl level
1: Low level
-
0
1
0
301
#
LCD.pullB_dow
n_up
Group B-Switch between high
level and low level (Pull B).
0: High level
1: Low level
-
0
1
0
