Detailed Information for Example 5
DescriptionItem
Whether the PCI is installed or not.
ON: Installed, OFF: Not installed
PCI ADP Equip
Example 6: removing additional MPB
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Remove,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
{MPB,Auto LDEV Assignment}
=[{MPB-1MB,Enable},{MPB-2MD,Enable},{MPB-1MF,Enable},
{MPB-2MH,Enable}],Num. of MPBs=4
Detailed Information for Example 6
DescriptionItem
The installed location of the MPB.MPB
The attribute of auto LDEV assignment.Auto LDEV Assignment
Example 7: removing additional SVP
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Remove,SVP,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{SVP}={SVP-OPTION}
+{IPAddress,Subnet Mask}={(123.456.789.123),(255.255.255.255)}
+Use Duplex=Invalid
+Svp Kind=Master SVP
+IPv4=Valid
+IPv6=Valid
+{M-SVP IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
={((111.222.333.444),(255.255.255.255)),
((1111:2222:3333:4444:5555:6666:7777:8888),(64))}
+{S-SVP IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
={((555.666.777.888),(255.255.255.255)),
((9999:AAAA:BBBB:CCCC:DDDD:EEEE:FFFF:0000),(64))}
Basic Information
DescriptionParameter
Indicates a change in the IP adress of the SVP.SVP
Indicates a change in the IP adress of the SVP and the DKC.SVP&DKC
Detailed Information for Example 7
DescriptionItem
The installed location of the SVP.SVP
IP address in the SVP.IPAddress
The subnet mask in the SVP.Subnet Mask
[Install] Cache Residency Prestaging 75
