[Install] Install
Example 1: installing additional channel adapters
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{CHA,Kind}={CHA-1EL,16FC (Fibre )},
++{Port,Initiator/Target,Channel Speed,CU Number}
=[{1C,Target,Auto,00:00-00:FE},{3C,Target,Auto,00:00-00:FE},
{5C,Target,Auto,00:00-00:FE},{7C,Target,Auto,00:00-00:FE},
{1D,Target,Auto,00:00-00:FE},{3D,Target,Auto,00:00-00:FE},
{5D,Target,Auto,00:00-00:FE},{7D,Target,Auto,00:00-00:FE}],
Num. of Ports=8
+{CHA,Kind}={CHA-1FU, 16MF(Mfibre)},
++{Port,HTP/FNP,CU Number,Emulation}
=[{1E,HTP,00:00-00:FE,I-2107},{3E,HTP,00:00-00:FE,I-2107},
{5E,HTP,00:00-00:FE,I-2107},
{7E,HTP,00:00-00:FE,I-2107},{1F,HTP,00:00-00:FE,I-2107},
{3F,HTP,00:00-00:FE,I-2107},{5F,HTP,00:00-00:FE,I-2107},
{7F,HTP,00:00-00:FE,I-2107}],Num. of Ports=8
+{CHA,Kind}={CHA-2QL,16FC (Fibre )},
++{Port,Initiator/Target,Channel Speed,CU Number}
=[{2C,Target,Auto,00:00-00:FE},{4C,Target,Auto,00:00-00:FE},
{6C,Target,Auto,00:00-00:FE},{8C,Target,Auto,00:00-00:FE},
{2D,Target,Auto,00:00-00:FE},{4D,Target,Auto,00:00-00:FE},
{6D,Target,Auto,00:00-00:FE},{8D,Target,Auto,00:00-00:FE}],
Num. of Ports=8
+{CHA,Kind}={CHA-2RU, 16MF(Mfibre)},
++{Port,HTP/FNP,CU Number,Emulation}
=[{2E,HTP,00:00-00:FE,I-2107},{4E,HTP,00:00-00:FE,I-2107},
{6E,HTP,00:00-00:FE,I-2107},{8E,HTP,00:00-00:FE,I-2107},
{2F,HTP,00:00-00:FE,I-2107},{4F,HTP,00:00-00:FE,I-2107},
{6F,HTP,00:00-00:FE,I-2107},{8F,HTP,00:00-00:FE,I-2107}],
Num. of Ports=8
+Num. of CHAs=4
Detailed Information for Example 1
DescriptionItem
The CHA mounting location.CHA
The kind of PCB mounted.Kind
The mounting location of the port.Port
The type of Initiator or Target.Initiator/Target
The channel speed is indicated for open systems.
1: 1 Gbps, 2: 2 Gbps, 4: 4 Gbps, 8: 8 Gbps, Auto: Auto mode.
Channel Speed
Indicates the range of the CU number that the port belongs.CU Number
The number of ports.Num. of Ports
The HTP or FNP is indicated for FICON.HTP/FNP
The emulation type is indicated for mainframe systems.Emulation
The number of CHAs.Num. of CHAs
Example 2: installing additional subsystems, ECC Groups or LDEVs
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,,Normal end,
[Install] Cache Residency Prestaging 63
