from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{DKA,Kind}=[{DKA-1AL,DKF 4MP},{DKA-1LL,DKF 4MP},
{DKA-2ML,DKF 4MP},{DKA-2XL,DKF 4MP}],Num. of DKAs=4
+{DKU,Kind}=[{DKU-11,2.5" DKU}],Num. of DKUs=1
+{PG,RAID Level,Drive Type,Protection Level,Emulation,
Concatenation,Encryption}
={3-1,RAID1 (2D+2D),DKR5C-J600SS,Standard,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,System Disk,SSID,MPB}
=[{0x00:0x05:0x00,OPEN-V,2251536384,LBA,Disable,0x0009,Auto}],
Num. of LDEVs=1
+{PG,RAID Level,Drive Type,Protection Level,
Emulation,Concatenation,Encryption}
={3-2,RAID5 (3D+1P),DKR5C-J600SS,Standard,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,System Disk,SSID,MPB}
=[{0x00:0x05:0x01,OPEN-V,3377304576,LBA,Disable,0x0009,Auto}],
Num. of LDEVs=1
+{PG,RAID Level,Drive Type,Protection Level,
Emulation,Concatenation,Encryption}
={3-3,RAID1 (2D+2D),DKR5C-J600SS,Standard,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,System Disk,SSID,MPB}
=[{0x00:0x05:0x02,OPEN-V,2251536384,LBA,Disable,0x0009,Auto}],
Num. of LDEVs=1
+Num. of PGs=3
+{B4,SPARE,Drive Type}=[{3,1,DKR5C-J600SS}],Num. of SPAREs=1
This logged information indicates that the formatting was only requested but not finished. If the
operation does not require the formatting, this logged information indicates that the volume was
created.
Basic Information for Example 2
DescriptionParameter
The progress window of LDEV format when LDEV is added is closed.Progress Close
Quick Format was selected when LDEV is added.Quick Format
The progress window of preparing for Quick Format is closed.Quick Format Close
Note: No parameter is output for any case other than those described in this table.
Detailed Information for Example 2
DescriptionItem
The Disk Adapter (DKA) mounting location.Disk Adapter (DKA)
The type of Disk Adapter (DKA).Kind
The number of Disk Adapter (DKA)s.Num. of Disk Adapter
(DKA)s
The mounting location of Disk Unit (DKU).Disk Unit (DKU)
The type of DKU.Kind
The number of Disk Unit (DKU).Num. of Disk Unit
(DKU)s
The parity group number.PG
The RAID Level.RAID Level
The type of the drive.Drive Type
The protection level.Protection Level
64 Audit log examples
