DescriptionItem
The emulation type.Emulation
The RAID concatenated parity group number. A hyphen (-) is indicated when the parity group
is not RAID concatenated.
Concatenation
The status of the encryption setting.
0-31: Encryption Key ID Disable: Disabled.
Encryption
The LDKC number, the CU number, and the LDEV number.LDKC:CU:LDEV
The capacity of CV.Size
The unit of the capacity of CV.Unit
The status of the system disk setting.
Disable or Enable will appear.
System Disk
The subsystem ID.SSID
The ownership of the MPB.MPB
The number of LDEVs.Num. of LDEVs
The number of parity groups.Num. of PGs
The B4 number.B4
The spare drive number.SPARE
The number of spare drives.Num. of SPAREs
Note: Only the changed items will be output. The Detailed Information of the recovery process will not be output when
the installation process executed before the process has completed. However, the setting of the recovery process will
be output as the Detailed Information of the process when the installation process executed before the recovery process
has not completed.
Example 3: installing additional cache memory
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{CM,CMG,size,SSD0,SSD1)}
=[{1CA/2CC,C16G,32768,BM64(64GB),0},
{1CB/2CD,C16G,32768,BM64(64GB),0},
{1CE/2CG,C16G,32768,BM64(64GB),BM64(64GB)},
{1CF/2CH,C16G,32768,BM64(64GB),BM128(128GB)}],Num. of CMs=4
+Cache Residency available Size=3328
+{CLPR,Cache size,Cache Residency size,ExtentNumber}
=[{CLPR0,117760,6656,16384}],Num. of CLPRs=1
+PP Flag=[<64KLDEV, SI/VM Extension1, FCV2, DP, CoW, TPF>,
<SI/VM Extension2, CoW Extension>],Num. of PP Flags=2
+Max Number of CUs=255
Detailed Information for Example 3
DescriptionItem
The mounting location of the PCB for cache memory.CM
The capacity of CMG.CMG
The capacity of cache memory.Size
The size of SSD0.SSD0
The size of SSD1.SSD1
[Install] Cache Residency Prestaging 65
