Icom ID-51A User Manual

16
MENU SCREEN
16-13
Selects the transceiver backlight option.
Selects the backlight ON time period.
Selects the LCD backlight brightness level.
Sets the contrast level of the LCD.
Turns the TX/RX indicator ON or OFF.
Display
Backlight
LCD Dimmer
LCD Contrast
Busy LED
OFF, ON, Auto or Auto (DC IN:ON)
In this item, set the Display options.
Bright or Dark
1~8~16
OFF or ON
Backlight Timer 5sec or 10sec
DESCRIPTIONSRANGE OR VALUE (Default is shown in bold)
RX Call Sign OFF, Auto or Auto (RX Hold)
Selects the call sign display option when
receiving a call.
TX Call Sign
Scroll Speed
Opening Message
Voltage (Power ON)
OFF, Your Call Sign or My Call Sign
Slow or Fast
OFF or ON
OFF or ON
DV RX Backlight
RX Message
OFF or ON
OFF or Auto
Selects to display and scroll a received
message when receiving a call, or not.
Turns the DV RX Backlight function ON or
OFF.
Selects whether or not to display My or
Your call sign while transmitting.
Selects the scrolling speed of the mes-
sage, call sign, or other text.
Selects whether or not to display the
opening message at power ON.
Selects whether or not to display the volt-
age of the battery or external DC power
source at power ON.
System Language English or Japanese
Selects English or Japanese as the sys-
tem language of the transceiver.
Display Language English or Japanese
Selects the display language in the DR
function or Menu mode. When "English"
is selected in System Language, this set-
ting will disappear.
Reply Position Display OFF or ON
Selects to display the caller's position
data when the data is included in the Auto
Reply signal, or not.
■ Menu items and Default settings (Continued)
NOTE: The default settings shown below are for the USA version.
The default settings may differ, depending on your transceiver version.
Function (Continued)
Heterodyne
Normal or Reverse
In this item, set other options.
DESCRIPTIONS
RANGE OR VALUE (Default is shown in bold)
Sets the 1st Local Oscillator frequency.
Charging (Power ON) OFF or ON
When the external DC power cable
is connected, this function enables
charging the battery even with the
power ON.
Display Unit
Selects position format to display the position.
Selects the units to display the distance
and altitude.
Selects the units to display the speed.
Selects the units to display the temperature.
Selects the units to display the barometric
pressure.
Selects the units to display the rainfall.
Selects the units to display the wind speed.
Latitude/Longitude
Altitude/Distance
Speed
Temperature
Barometric
Rainfall
Wind Speed
ddd ºmm.mm' or ddd ºmm'ss''
m or ft/ml
*1
km/h, mph
*1
or knots
ºC or ºF
*1
hPa, mb, mmHg, inHg
*1
mm or inch
*1
m/s, mph
*1
, knots
*
1
The default value may differ, depending on the transceiver version.
