Table 107. Types of Register Access
Access Definition
RO Read only.
RW Read and write.
RWC Read, and write and clear. The user application writes 1 to the register bit(s) to invoke a defined
instruction. The IP core clears the bit(s) upon executing the instruction.
Table 108. PHY Register Definitions
Addr Name Description Access HW Reset
Value
0x400
usxgmii_control
Control Register — —
Bit [0]: USXGMII_ENA:
• 0: 10GBASE-R mode
• 1: USXGMII mode
RW 0x0
Bit [1]: USXGMII_AN_ENA is used when USXGMII_ENA
is set to 1:
• 0: Disables USXGMII Auto-Negotiation and manually
configures the operating speed with the
USXGMII_SPEED register.
• 1: Enables USXGMII Auto-Negotiation, and
automatically configures operating speed with link
partner ability advertised during USXGMII Auto-
Negotiation.
RW 0x1
Bit [4:2]: USXGMII_SPEED is the operating speed of
the PHY in USXGMII mode and USE_USXGMII_AN is set
to 0.
• 3’b000: 10M
• 3’b001: 100M
• 3’b010: 1G
• 3’b011: 10G
• 3’b100: 2.5G
• 3’b101: 5G
• 3’b110: Reserved
• 3’b111: Reserved
RW 0x0
Bit [8:5]: Reserved — —
Bit [9]: RESTART_AUTO_NEGOTIATION
Write 1 to restart Auto-Negotiation sequence The bit is
cleared by hardware when Auto-Negotiation is
restarted.
RWC
(hardw
are
self-
clear)
0x0
Bit [15:10]: Reserved — —
Bit [30:16]: Reserved — —
0x401
usxgmii_status
Status Register — —
Bit [1:0]: Reserved — —
Bit [2]: LINK_STATUS indicates link status for USXGMII
all speeds
• 1: Link is established
• 0: Link synchronization is lost, a 0 is latched
RO 0x0
Bit [3]: Reserved — —
continued...
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
114
