Intel Cyclone 10 GX User Manual

Protocol Transceiver PHY IP
Core
PCS Support Transceiver
Configuration Rule
Protocol Preset
SONET/SDH STS-192/
STM-64 (10G) via SFP
+/SFF-8431/CEI-11G
Native PHY IP core Enhanced Basic (Enhanced PCS) User created
SONET/SDH STS-192/
STM-64 (10G) via OIF
SFI-5.1s/SxI-5/
SFI-4.2
Native PHY IP core Enhanced Basic (Enhanced PCS) User created
SONET STS-96 (5G)
via OIF SFI-5.1s
Native PHY IP core Enhanced Basic/Custom
(Standard PCS)
SONET/SDH OC-96
SONET/SDH STS-48/
STM-16 (2.5G) via
SFP/TFI-5.1
Native PHY IP core Standard Basic/Custom
(Standard PCS)
SONET/SDH OC-48
SONET/SDH STS-12/
STM-4 (0.622G) via
SFP/TFI-5.1
Native PHY IP core
(7)
Standard Basic/Custom
(Standard PCS)
SONET/SDH OC-12
SD-SDI/HD-
SDI/3G/6G/12G-SDI
Native PHY IP core Standard Basic/Custom
(Standard PCS)
HD/3G SDI NTSC/PAL
SDI multi-rate (up to
12G) RX/TX
SDI triple-rate RX
Vx1 Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
DisplayPort Native PHY IP core Standard Basic/Custom
(Standard PCS)
DisplayPort Duplex 4
SYMBOLS PER CLOCK
DisplayPort RX 4
SYMBOLS PER CLOCK
DisplayPort TX 4
SYMBOLS PER CLOCK
1.25G/ 2.5G
10G GPON/EPON
Native PHY IP core Enhanced Basic (Enhanced PCS) User created
2.5G/1.25G GPON/
EPON
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
8G/4G/2G/1G Fibre
Channel
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
SDR/DDR Infiniband
x1, x4, x12
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
SRIO 2.2/1.3 Native PHY IP core Standard Basic/Custom with
Rate Match(Standard
PCS)
Serial Rapid IO 1.25
Gbps
CPRI 4.1/OBSAI RP3
v4.1
Native PHY IP core Standard CPRI (Auto)/CPRI
(Manual)
User created
(8)
SAS 3.0 Native PHY IP core Enhanced Basic (Enhanced PCS) User created
continued...
(7)
The minimum operational data rate is 1.0 Gbps for both the transmitter and receiver. If
transmitter data rates less than 1.0 Gbps, oversampling must be applied at the transmitter. If
receiver data rates less than 1.0 Gbps, oversampling must be applied at the receiver.
(8)
Select CPRI 9.8 Gbps Auto/Manual Mode (Intel Arria
®
10 only). Then change the datarate
from 9830.4 Mbps to 6144 Mbps.
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
25
