Intel Cyclone 10 GX User Manual

Table 4. General, Common PMA Options, and Datapath Options
Parameter Value Description
Message level for rule
violations
error
warning
Specifies the messaging level for parameter rule violations.
Selecting error causes all rule violations to prevent IP generation.
Selecting warning displays all rule violations as warnings in the
message window and allows IP generation despite the violations.
VCCR_GXB and
VCCT_GXB supply
voltage for the
Transceiver
0_9V, 1_0V
Selects the VCCR_GXB and VCCT_GXB supply voltage for the
Transceiver.
Note: This option is only used for GUI rule validation. Use
Quartus Prime Setting File (.qsf) assignments to set this
parameter in your static design.
Transceiver Link Type sr, lr Selects the type of transceiver link. sr-Short Reach (Chip-to-chip
communication), lr-Long Reach (Backplane communication).
Note: This option is only used for GUI rule validation. Use
Quartus Prime Setting File (.qsf) assignments to set this
parameter in your static design.
Transceiver
configuration rules
User Selection Specifies the valid configuration rules for the transceiver.
This parameter specifies the configuration rule against which the
Parameter Editor checks your PMA and PCS parameter settings
for specific protocols. Depending on the transceiver configuration
rule selected, the Parameter Editor validates the parameters and
options selected by you and generates error messages or warnings
for all invalid settings.
To determine the transceiver configuration rule to be selected for
your protocol, refer to Table 3 on page 24 Transceiver
Configuration Rule Parameters table for more details about each
transceiver configuration rule.
This parameter is used for rule checking and is not a preset. You
need to set all parameters for your protocol implementation.
PMA configuration
rules
Basic
SATA/SAS
GPON
Specifies the configuration rule for PMA.
Select Basic for all other protocol modes except for SATA and
GPON .
SATA (Serial ATA) can be used only if the Transceiver
configuration rule is set to Basic/Custom (Standard PCS).
GPON can be used only if the Transceiver configuration rule is
set to Basic (Enhanced PCS).
Transceiver mode TX/RX Duplex
TX Simplex
RX Simplex
Specifies the operational mode of the transceiver.
• TX/RX Duplex : Specifies a single channel that supports both
transmission and reception.
• TX Simplex : Specifies a single channel that supports only
transmission.
• RX Simplex : Specifies a single channel that supports only
reception.
The default is TX/RX Duplex.
Number of data
channels
1 – <n> Specifies the number of transceiver channels to be implemented.
The maximum number of channels available, ( <n> ), depends on
the package you select.
The default value is 1.
Data rate < valid Transceiver data
rate >
Specifies the data rate in megabits per second (Mbps).
Enable datapath and
interface
reconfiguration
On/Off When you turn this option on, you can preconfigure and
dynamically switch between the Standard PCS, Enhanced PCS, and
PCS direct datapaths.
continued...
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
29
