Intel Cyclone 10 GX User Manual

Table 204. Register Map for PRBS Checker for bonded and non bonded designs
Description Reconfiguration
Address
Reconfiguration
Bits
Value Attribute
Encoding
Attribute Name
Enable PRBS checker clock 0x00A [7] 1'b1 prbs_clk_en prbs_clken
Disable PRBS checker clock 1'b0 prbs_clk_dis
Mask out the initial errors
(from error counter
threshold to 1023) seen by
PRBS checker
0x00B [3:2] 2'b11 prbsmask1024 rx_prbs_mask
Mask out the initial errors
(from error counter
threshold to 127) seen by
PRBS checker
2'b00 prbsmask128
Mask out the initial errors
(from error counter
threshold to 255) seen by
PRBS checker
2'b01 prbsmask256
Mask out the initial errors
(from error counter
threshold to 511) seen by
PRBS checker
2'b10 prbsmask512
Enable PRBS 7 pattern 0x00B [7:4] 4'b0001 prbs_7 prbs_ver
0x00C [0] 1'b0
Enable PRBS 9 pattern 0x00B [7:4] 4'b0010 prbs_9
0x00C [0] 1'b0
Enable PRBS 15 pattern 0x00B [7:4] 4'b0100 prbs_15
0x00C [0] 1'b0
Enable PRBS 23 pattern 0x00B [7:4] 4'b1000 prbs_23
0x00C [0] 1'b0
Enable PRBS 31 pattern 0x00B [7:4] 4'b0000 prbs_31
0x00C [0] 1'b1
PRBS 9 10-bit 0x00C [3] 1'b1 prbs9_10b prbs9_dwidth
PRBS 9 64-bit 1'b0 prbs9_64b
Deserialization factor 10-bit
mode
0x13F [3:0] 4'b0001 10-bit mode deser_factor
Deserialization factor 64-bit
mode
4'b1110 64-bit mode
(31)
The pattern generators and checkers are supported only for non-bonded channels. If original
design is bonded and you would like to use the PRBS generator/checker, you must read and
save the value in registers 0x119[0], 0x111[4:0] before changing the
x1_clock_source_sel settings to xN_non_bonding (by writing 5'b11000 to 0x119[0],
0x111[4:0]). This will change the design from bonded to non-bonded.
To disable the PRBS generator and restore the design back to original bonded design, you
need to restore the original value that was previously saved from registers 0x119[0],
0x111[4:0].
6. Reconfiguration Interface and Dynamic Reconfiguration
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
362
