Name Direction Clock Domain Description
the FIFO
rx_coreclkin
or rx_clkout
Refer to Enhanced PCS FIFO Operation on page 164
for more details.
rx_enh_fifo_empty[<n>
-1:0]
Output Synchronous to
the clock driving
the read side of
the FIFO
rx_coreclkin
or rx_clkout
When asserted, indicates that the RX FIFO is empty.
Because the depth is always constant, you can ignore
this signal for the phase compensation mode.
Refer to Enhanced PCS FIFO Operation on page 164
for more details.
rx_enh_fifo_pempty[<n
>-1:0]
Output Synchronous to
the clock driving
the read side of
the FIFO
rx_coreclkin
or rx_clkout
When asserted, indicates that the RX FIFO has
reached its specified partially empty threshold.
Because the depth is always constant, you can ignore
this signal for the phase compensation mode.
Refer to Enhanced PCS FIFO Operation on page 164
for more details.
rx_enh_fifo_del[<n>-1
:0]
Output Synchronous to
the clock driving
the read side of
the FIFO
rx_coreclkin
or rx_clkout
When asserted, indicates that a word has been deleted
from the RX FIFO. This signal gets asserted for 2 to 3
clock cycles. This signal is used for the 10GBASE-R
protocol.
rx_enh_fifo_insert[<n
>-1:0]
Output Synchronous to
the clock driving
the read side of
the FIFO
rx_coreclkin
or rx_clkout
When asserted, indicates that a word has been
inserted into the RX FIFO. This signal is used for the
10GBASE-R protocol.
rx_enh_fifo_rd_en[<n>
-1:0]
Output Synchronous to
the clock driving
the read side of
the FIFO
rx_coreclkin
or rx_clkout
For Interlaken only, when this signal is asserted, a
word is read form the RX FIFO. You need to control
this signal based on RX FIFO flags so that the FIFO
does not underflow or overflow.
rx_enh_fifo_align_va
l[<n>-1:0]
Input Synchronous to
the clock driving
the read side of
the FIFO
rx_coreclkin
or rx_clkout
When asserted, indicates that the word alignment
pattern has been found. This signal is only valid for
the Interlaken protocol.
rx_enh_fifo_align_cl
r[<n>-1:0]
Input Synchronous to
the clock driving
the read side of
the FIFO
rx_coreclkin
or rx_clkout
When asserted, the FIFO resets and begins searching
for a new alignment pattern. This signal is only valid
for the Interlaken protocol. Assert this signal for at
least 4 cycles.
Table 47. Interlaken Frame Generator, Synchronizer, and CRC32
Name Direction Clock Domain Description
tx_enh_frame[<n>-1:0]
Output
tx_clkout
Asserted for 2 or 3 parallel clock cycles to indicate the
beginning of a new metaframe.
tx_enh_frame_diag_stat
us[<n> 2-1:0]
Input
tx_clkout
Drives the lane status message contained in the framing
layer diagnostic word (bits[33:32]). This message is
inserted into the next diagnostic word generated by the
continued...
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
57
