Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1189
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02284 LS_WriteParamList: VFC: limitation V/f
+encoder
Linear value 22291 5713 A 8 UNSIGNED_16 100
C02285
LS_WriteParamList: VFC: Vp V/f +encoder Linear value 22290 5712 A 4 UNSIGNED_16 1000
C02286
LS_WriteParamList: VFC: Ti V/f +encoder Linear value 22289 5711 A 4 UNSIGNED_16 10
C02287
LS_WriteParamList: VFC-ECO: Vp CosPhi
controller
Linear value 22288 5710 A 4 UNSIGNED_16 1000
C02288
LS_WriteParamList: VFC-ECO: Ti CosPhi
controller
Linear value 22287 570F A 4 UNSIGNED_16 10
C02289
LS_WriteParamList: VFC-ECO: Minimum
voltage U/f
Linear value 22286 570E A 4 INTEGER_16 100
C02290
LS_WriteParamList: VFC-ECO: Voltage
reduction ramp
Linear value 22285 570D A 4 UNSIGNED_8 10
C02291
LS_WriteParamList: SLVC: Field current
controller gain
Linear value 22284 570C A 4 INTEGER_16 100
C02292
LS_WriteParamList: SLVC: Cross current
controller gain
Linear value 22283 570B A 4 INTEGER_16 100
C02293
LS_WriteParamList: Inverter motor brake:
nAdd
Linear value 22282 570A A 4 INTEGER_16 1
C02294
LS_WriteParamList: Inverter motor brake:
PT1 filter time
Linear value 22281 5709 A 4 INTEGER_16 10
C02295
LS_WriteParamList: Flying restart fct.:
activation
Selection list 22280 5708 A 4 UNSIGNED_8 1 CINH
C02296
LS_WriteParamList: Flying restart fct.:
process
Selection list 22279 5707 A 4 UNSIGNED_16 1
C02297
LS_WriteParamList: Flying restart: start
frequency
Linear value 22278 5706 A 4 INTEGER_16 1
C02298
LS_WriteParamList: Flying restart fct: int.
time
Linear value 22277 5705 A 4 UNSIGNED_16 10
C02299
LS_WriteParamList: Flying restart fct.:
current
Linear value 22276 5704 A 4 INTEGER_16 100
C02300
LS_WriteParamList: SLPSM: Controlled
current setpoint
Linear value 22275 5703 A 8 UNSIGNED_16 100
C02301
LS_WriteParamList: SLPSM: Switching
speed
Linear value 22274 5702 A 8 INTEGER_16 100
C02302
LS_WriteParamList: SLPSM: Filter time -
rotor position
Linear value 22273 5701 A 4 INTEGER_16 100
C02303
LS_WriteParamList: SLPSM: Filter time
rotor position
Linear value 22272 5700 A 8 INTEGER_16 10
C02304
LS_WriteParamList: SLPSM: PLL gain Linear value 22271 56FF A 4 INTEGER_16 1
C02305
LS_WriteParamList: PSM: Ppp saturation
characteristic
Linear value 22270 56FE A 68 UNSIGNED_8 1
C02306
LS_WriteParamList: PSM: Imax Ppp
saturation characteristic
Linear value 22269 56FD A 4 UNSIGNED_16 10
C02307
LS_WriteParamList: PSM: Activate Ppp
saturation char.
Selection list 22268 56FC A 4 UNSIGNED_8 1
C02311
LS_WriteParamList: PLI without motion:
Adaptation of time duration
Linear value 22264 56F8 A 4 INTEGER_8 1
C02312
LS_WriteParamList: PLI without motion Bit coded 22263 56F7 A 4 UNSIGNED_16 1
C02313
LS_WriteParamList: PLI without motion:
Adaptation of ident angle
Linear value 22262 56F6 A 4 INTEGER_8 1
C02315
LS_WriteParamList: Manual entry of
motor type
Selection list 22260 56F4 A 4 UNSIGNED_8 1
C02556
Position controller: Limitation Linear value 22019 5603 A 1 INTEGER_32 1
C02580
Holding brake: Operating mode Selection list 21995 55EB E 1 UNSIGNED_8 1
C02581
Holding brake: Speed thresholds Linear value 21994 55EA A 5 INTEGER_16 100
C02582
Holding brake: Setting Bit coded 21993 55E9 E 1 UNSIGNED_8 1
C02589
Holding brake: Time system Linear value 21986 55E2 A 4 UNSIGNED_16 1
C02593
Holding brake: Activation time Linear value 21982 55DE A 4 UNSIGNED_32 1000
C02607
Holding brake: Status Bit coded 21968 55D0 E 1 UNSIGNED_16 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
