15 Parameter reference
15.7 Table of attributes
1188
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02226 LS_WriteParamList: Ti current controller Linear value 22349 574D A 4 UNSIGNED_16 100
C02227
LS_WriteParamList: SC: Vp field controller Linear value 22348 574C A 4 UNSIGNED_16 100
C02228
LS_WriteParamList: SC: Tn field controller Linear value 22347 574B A 4 UNSIGNED_16 10
C02229
LS_WriteParamList: SC: settings Selection list 22346 574A A 16 UNSIGNED_8 1
C02230
LS_WriteParamList: Override point of field
weakening
Linear value 22345 5749 A 4 INTEGER_16 1
C02231
LS_WriteParamList: Rated motor power Linear value 22344 5748 A 4 UNSIGNED_16 100
C02232
LS_WriteParamList: Motor rotor resistance Linear value 22343 5747 A 4 UNSIGNED_32 1
C02233
LS_WriteParamList: Motor stator
resistance
Linear value 22342 5746 A 4 UNSIGNED_32 1
C02234
LS_WriteParamList: Motor stator leakage
inductance
Linear value 22341 5745 A 4 UNSIGNED_16 100
C02236
LS_WriteParamList: Rated motor speed Linear value 22339 5743 A 4 UNSIGNED_16 1
C02237
LS_WriteParamList: Rated motor current Linear value 22338 5742 A 4 UNSIGNED_16 100
C02238
LS_WriteParamList: Rated motor
frequency
Linear value 22337 5741 A 4 UNSIGNED_16 1
C02239
LS_WriteParamList: Rated motor voltage Linear value 22336 5740 A 4 UNSIGNED_16 1
C02240
LS_WriteParamList: Motor cosine phi Linear value 22335 573F A 4 UNSIGNED_8 100
C02241
LS_WriteParamList: Motor magnetizing
inductance
Linear value 22334 573E A 4 UNSIGNED_16 10
C02242
LS_WriteParamList: Motor magnetising
current
Linear value 22333 573D A 4 UNSIGNED_16 100
C02244
LS_WriteParamList: Auto-DCB: hold time Linear value 22331 573B A 4 UNSIGNED_32 1000
C02245
LS_WriteParamList: DC braking: Hold time Linear value 22330 573A A 4 UNSIGNED_32 1000
C02246
LS_WriteParamList: Setting of motor
overload (I²xt)
Linear value 22329 5739 A 4 INTEGER_16 100
C02249
LS_WriteParamList: Oscillation damping
influence
Linear value 22326 5736 A 4 UNSIGNED_16 100
C02250
LS_WriteParamList: Filter time - oscill.
damping
Linear value 22325 5735 A 4 UNSIGNED_8 1
C02251
LS_WriteParamList: Oscillation damping
field weakening
Linear value 22324 5734 A 4 UNSIGNED_8 1
C02252
LS_WriteParamList: Kp position controller Linear value 22323 5733 A 4 UNSIGNED_16 100
C02256
LS_WriteParamList: Moment of inertia Linear value 22319 572F A 4 UNSIGNED_32 100
C02260
LS_WriteParamList: Speed sensor
selection
Selection list 22315 572B A 4 UNSIGNED_8 1
C02261
LS_WriteParamList: SC: Field feedforward
control
Linear value 22314 572A A 4 UNSIGNED_16 1
C02262
LS_WriteParamList: SC: Vp field
weakening controller
Linear value 22313 5729 A 4 UNSIGNED_16 10000
C02263
LS_WriteParamList: SC: Tn field
weakening controller
Linear value 22312 5728 A 4 UNSIGNED_16 10
C02264
LS_WriteParamList: Sensibility - Setpoint
feedforward control
Selection list 22311 5727 A 4 UNSIGNED_8 1
C02272
LS_WriteParamList: Motor phase direction
of rotation
Selection list 22303 571F A 4 UNSIGNED_8 1 CINH
C02273
LS_WriteParamList: Speed limitation Linear value 22302 571E A 8 INTEGER_16 100
C02274
LS_WriteParamList: Frequency limitation Linear value 22301 571D A 8 UNSIGNED_16 1
C02275
LS_WriteParamList: Motor cable length Linear value 22300 571C A 4 UNSIGNED_16 10
C02276
LS_WriteParamList: Motor cable cross-
section
Linear value 22299 571B A 4 UNSIGNED_16 100
C02278
LS_WriteParamList: PSM: Maximum
motor current field weakening
Linear value 22297 5719 A 4 UNSIGNED_16 100
C02279
LS_WriteParamList: Ultimate motor
current
Linear value 22296 5718 A 4 UNSIGNED_16 10
C02280
LS_WriteParamList: Max. motor speed Linear value 22295 5717 A 4 UNSIGNED_16 1
C02281
LS_WriteParamList: VFC: Time const. slip
comp.
Linear value 22294 5716 A 4 UNSIGNED_16 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
