Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1187
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01299 MCKI: Status MCKInterface Bit coded 23276 5AEC E 1 UNSIGNED_8 1
C01300 Profile data: Positioning mode Selection list 23275 5AEB A 15 UNSIGNED_8 1
C01301
Profile data: Position Linear value 23274 5AEA A 15 INTEGER_32 10000
C01302
Profile data: Speed Linear value 23273 5AE9 A 15 INTEGER_32 10000
C01303
Profile data: Acceleration Linear value 23272 5AE8 A 15 INTEGER_32 10000
C01304
Profile data: Deceleration Linear value 23271 5AE7 A 15 INTEGER_32 10000
C01305
Profile data: Final speed Linear value 23270 5AE6 A 15 INTEGER_32 10000
C01306
Profile data: S-ramp time Linear value 23269 5AE5 A 15 UNSIGNED_16 1000
C01307
Profile data: Sequence profile Linear value 23268 5AE4 A 15 UNSIGNED_8 1
C01308
Profile data: TP profile Linear value 23267 5AE3 A 15 UNSIGNED_8 1
C01309
Profile data: TP signal source Selection list 23266 5AE2 A 15 UNSIGNED_8 1
C01350
ACDrive: Drive mode Selection list 23225 5AB9 A 1 UNSIGNED_8 1
C01351
ACDrive: Control word Bit coded 23224 5AB8 A 1 UNSIGNED_16 1
C01352 ACDrive: Status word Bit coded 23223 5AB7 A 1 UNSIGNED_16 1
C01353 ACDrive: Setpoint scaling Linear value 23222 5AB6 A 2 INTEGER_8 1
C01469
L_MFail: Vp Linear value 23106 5A42 A 1 UNSIGNED_16 1000
C01470
L_MFail: Tn Linear value 23105 5A41 A 3 UNSIGNED_16 1
C01501
Resp. to communication error with MCI Selection list 23074 5A22 A 2 UNSIGNED_8 1
C01670
L_ComparePhi 1-5: Function Selection list 22905 5979 A 5 UNSIGNED_8 1
C01671
L_ComparePhi 1-5: Hysteresis Linear value 22904 5978 A 5 INTEGER_32 1
C01672
L_ComparePhi 1-5: Window Linear value 22903 5977 A 5 INTEGER_32 1
C01700
Energy saving mode: Mode Linear value 22875 595B A 2 UNSIGNED_8 1
C01701 Energy saving mode: toff min Linear value 22874 595A A 1 UNSIGNED_16 1
C01702
Energy saving mode: toff Linear value 22873 5959 A 1 UNSIGNED_16 1
C01703
Energy saving mode: ton Linear value 22872 5958 A 1 UNSIGNED_16 1
C01704
Energy saving mode: Function Bit coded 22871 5957 A 1 UNSIGNED_16 1
C01709
Energy saving mode: Status Linear value 22866 5952 A 1 UNSIGNED_8 1
C01770 Filter time - earth-fault detect. is running Linear value 22805 5915 E 1 UNSIGNED_8 1
C01902
Diagnostics X6: Max. baud rate Selection list 22673 5891 E 1 UNSIGNED_16 1
C01903
Diagnostics X6: Change baud rate Selection list 22672 5890 E 1 UNSIGNED_8 1
C01905
Diagnostics X6: Current baud rate Linear value 22670 588E E 1 UNSIGNED_32 1
C02200 LS_WriteParamList: Function Selection list 22375 5767 A 2 UNSIGNED_8 1
C02210
LS_WriteParamList: Motor control Selection list 22365 575D A 4 UNSIGNED_8 1
C02212
LS_WriteParamList: VFC: V/f base
frequency
Linear value 22363 575B A 4 UNSIGNED_16 10
C02213
LS_WriteParamList: VFC: Vmin boost Linear value 22362 575A A 4 UNSIGNED_16 100
C02214
LS_WriteParamList: Switching frequency Selection list 22361 5759 A 4 UNSIGNED_8 1
C02215
LS_WriteParamList: Auto-DCB: Threshold Linear value 22360 5758 A 4 UNSIGNED_16 1
C02216
LS_WriteParamList: Slip compensation Linear value 22359 5757 A 4 INTEGER_16 100
C02217
LS_WriteParamList: Imax in motor mode Linear value 22358 5756 A 4 UNSIGNED_16 100
C02218
LS_WriteParamList: Imax in generator
mode
Linear value 22357 5755 A 4 INTEGER_16 100
C02219
LS_WriteParamList: DC braking: Current Linear value 22356 5754 A 4 INTEGER_16 100
C02220
LS_WriteParamList: Vp speed controller Linear value 22355 5753 A 12 UNSIGNED_16 100
C02221
LS_WriteParamList: Ti speed controller Linear value 22354 5752 A 12 UNSIGNED_16 10
C02222
LS_WriteParamList: SC: Tdn speed
controller
Linear value 22353 5751 A 4 UNSIGNED_16 100
C02223
LS_WriteParamList: Imax/M controller
gain
Linear value 22352 5750 A 8 UNSIGNED_16 100
C02224
LS_WriteParamList: Imax/M controller
reset time
Linear value 22351 574F A 8 UNSIGNED_16 1
C02225
LS_WriteParamList: Vp current controller Linear value 22350 574E A 4 UNSIGNED_16 100
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
