15 Parameter reference
15.7 Table of attributes
1186
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01201 MCK: Cycle Linear value 23374 5B4E A 1 INTEGER_32 10000
C01202
MCK: iM motor/process Linear value 23373 5B4D A 2 UNSIGNED_16 1
C01203
MCK: iG motor/position encoder Linear value 23372 5B4C A 2 UNSIGNED_16 1
C01204
MCK: Feed constant Linear value 23371 5B4B E 1 INTEGER_32 10000
C01205
MCK: Position resolution Linear value 23370 5B4A E 1 INTEGER_32 10000
C01206 MCK: Mounting direction Selection list 23369 5B49 A 2 UNSIGNED_8 1 CINH
C01210
MCK: Current positions Linear value 23365 5B45 A 9 INTEGER_32 10000
C01211 MCK: Speed Linear value 23364 5B44 A 3 INTEGER_32 10000
C01213 MCK: Max. traversing distance Linear value 23362 5B42 A 1 INTEGER_32 1
C01215 MCK: Following error Linear value 23360 5B40 A 3 INTEGER_32 10000
C01216
MCK: Positioning setting Bit coded 23359 5B3F E 1 UNSIGNED_8 1
C01218
MCK: Position follower setting Bit coded 23357 5B3D E 1 UNSIGNED_8 1
C01219
MCK: Speed follower setting Bit coded 23356 5B3C E 1 UNSIGNED_8 1
C01220
MCK: Ref. setting Bit coded 23355 5B3B A 1 UNSIGNED_16 1
C01221
MCK: Homing mode Selection list 23354 5B3A E 1 UNSIGNED_8 1
C01222
MCK: Ref. M limit mode 14/15 Linear value 23353 5B39 E 1 INTEGER_16 100
C01223
MCK: Ref. waiting time mode 14/15 Linear value 23352 5B38 E 1 UNSIGNED_16 1
C01224
MCK: Ref. speeds Linear value 23351 5B37 A 2 INTEGER_32 10000
C01225
MCK: Ref. accelerations Linear value 23350 5B36 A 2 INTEGER_32 10000
C01226
MCK: Ref. S-ramp time Linear value 23349 5B35 A 1 UNSIGNED_16 1000
C01227
MCK: Ref. positions Linear value 23348 5B34 A 2 INTEGER_32 10000
C01228
MCK: Ref. sequence profile Linear value 23347 5B33 E 1 UNSIGNED_8 1
C01229
MCK: Position limiting values Linear value 23346 5B32 A 2 INTEGER_32 10000
C01230
Manual jog: Setting Bit coded 23345 5B31 E 1 UNSIGNED_8 1
C01231
MCK: Manual jog speeds Linear value 23344 5B30 A 2 INTEGER_32 10000
C01232
MCK: Manual jog accelerations Linear value 23343 5B2F A 2 INTEGER_32 10000
C01233
MCK: Manual jog S-ramp time Linear value 23342 5B2E A 1 UNSIGNED_16 1000
C01234
MCK: Manual jog breakpoints Linear value 23341 5B2D A 4 INTEGER_32 10000
C01235
MCK: Manual jog waiting times Linear value 23340 5B2C A 1 UNSIGNED_16 1000
C01236
MCK: Speed follower Linear value 23339 5B2B A 1 INTEGER_32 10000
C01237
MCK: Acceleration follower Linear value 23338 5B2A A 2 INTEGER_32 10000
C01238
MCK: S-ramp time follower Linear value 23337 5B29 A 1 UNSIGNED_16 1000
C01239
Setpoint holding Linear value 23336 5B28 E 1 UNSIGNED_32 1
C01240
MCK: Control word Bit coded 23335 5B27 E 1 UNSIGNED_32 1
C01241 MCK: Status word Bit coded 23334 5B26 E 1 UNSIGNED_32 1
C01242 MCK: Current pos profile number Linear value 23333 5B25 E 1 UNSIGNED_8 1
C01243 MCK: Current operating mode Selection list 23332 5B24 E 1 UNSIGNED_8 1
C01244 MCK: Target detection - times Linear value 23331 5B23 A 3 UNSIGNED_16 1
C01245
MCK: Target detection - positions Linear value 23330 5B22 A 3 INTEGER_32 10000
C01246
MCK: Select signal source Selection list 23329 5B21 A 2 UNSIGNED_8 1
C01247
MCK: Diagnostic word Bit coded 23328 5B20 E 1 UNSIGNED_32 1
C01248 MCK: Ref. step Selection list 23327 5B1F A 1 UNSIGNED_8 1
C01251 MCK: Acceleration stop Linear value 23324 5B1C A 1 INTEGER_32 10000
C01252
MCK: S-ramp times stop Linear value 23323 5B1B A 1 UNSIGNED_16 1000
C01294
Mode: Position calculation Selection list 23281 5AF1 A 3 UNSIGNED_8 1
C01295
L_MCKStateInterface_1: Pos. selection Selection list 23280 5AF0 E 1 UNSIGNED_8 1
C01296
Mode: Position calculation Selection list 23279 5AEF A 2 UNSIGNED_8 1
C01297
L_MckCtrlInterface_1: Alternative
function
Bit coded 23278 5AEE E 1 UNSIGNED_8 1
C01298
MCK: Operating mode change with profile
no.
Selection list 23277 5AED A 4 UNSIGNED_8 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
