Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1185
15 Parameter reference
15.7 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01068 L_SwitchPoint_1: Invert Bit coded 23507 5BD3 A 1 UNSIGNED_16 1
C01069
L_DFSET_1: Ramp settings Linear value 23506 5BD2 A 2 UNSIGNED_16 1
C01070
L_DFSET_1: Angular trimming Linear value 23505 5BD1 A 1 INTEGER_32 1
C01071
L_DFSET_1: Following error limit Linear value 23504 5BD0 A 1 UNSIGNED_32 1
C01072
L_DFSET_1: Multiplier - angular trimming Linear value 23503 5BCF A 1 INTEGER_16 1
C01073
L_DFSET_1: Adjustment Bit coded 23502 5BCE A 1 UNSIGNED_8 1
C01074
L_DFSET_1: Zero pulse divider Linear value 23501 5BCD A 2 UNSIGNED_16 1
C01075
L_DFSET_1: Synchronisation mode Selection list 23500 5BCC A 1 UNSIGNED_8 1
C01076
L_DFRFG_1: Times Linear value 23499 5BCB A 2 UNSIGNED_32 1000
C01077
L_DFRFG_1: Max. speed-up Linear value 23498 5BCA A 1 INTEGER_16 1
C01078
L_DFRFG_1: Following error Linear value 23497 5BC9 A 1 UNSIGNED_32 1
C01079
L_DFRFG_1: Synchronisation window Linear value 23496 5BC8 A 1 UNSIGNED_16 1
C01080
L_DFRFG_1: Offset Linear value 23495 5BC7 A 1 INTEGER_32 1
C01081
L_DFRFG_1: Sync. direction / TP function Selection list 23494 5BC6 A 1 UNSIGNED_8 1
C01082
LS_WriteParamList: Execute Mode Selection list 23493 5BC5 E 1 UNSIGNED_8 1
C01083
LS_WriteParamList: Error status Linear value 23492 5BC4 E 1 UNSIGNED_16 1
C01084 LS_WriteParamList: Error line Linear value 23491 5BC3 E 1 UNSIGNED_8 1
C01085 LS_WriteParamList: Index Linear value 23490 5BC2 A 32 INTEGER_32 1000
C01086
LS_WriteParamList: WriteValue_1 Linear value 23489 5BC1 A 32 INTEGER_32 1
C01087
LS_WriteParamList: WriteValue_2 Linear value 23488 5BC0 A 32 INTEGER_32 1
C01088
LS_WriteParamList: WriteValue_3 Linear value 23487 5BBF A 32 INTEGER_32 1
C01089
LS_WriteParamList: WriteValue_4 Linear value 23486 5BBE A 32 INTEGER_32 1
C01090
LS_ParReadWrite 1-6: Index Linear value 23485 5BBD A 6 INTEGER_32 1000
C01091
LS_ParReadWrite 1-6: Cycle time Selection list 23484 5BBC A 6 UNSIGNED_16 1
C01092
LS_ParReadWrite 1-6: FailState Linear value 23483 5BBB A 6 UNSIGNED_16 1
C01093 LS_ParReadWrite 1-6: Arithmetic mode Selection list 23482 5BBA A 6 UNSIGNED_8 1
C01094
LS_ParReadWrite 1-6: Numerator Linear value 23481 5BB9 A 6 INTEGER_16 1
C01095
LS_ParReadWrite 1-6: Denominator Linear value 23480 5BB8 A 6 INTEGER_16 1
C01098
LS_ParReadWrite 1-6: Configuration Bit coded 23477 5BB5 A 6 UNSIGNED_16 1
C01100
Function L_Counter 1-3 Selection list 23475 5BB3 A 3 UNSIGNED_8 1
C01101
Comparison L_Counter 1-3 Selection list 23474 5BB2 A 3 UNSIGNED_8 1
C01108
L_SwitchPoint_1: Deadtime factor Selection list 23467 5BAB A 4 UNSIGNED_8 1
C01120
Sync signal source Selection list 23455 5B9F E 1 UNSIGNED_8 1
C01121
Sync cycle time setpoint Linear value 23454 5B9E E 1 UNSIGNED_16 1
C01122
Sync phase position Linear value 23453 5B9D E 1 UNSIGNED_16 1
C01123
Sync window Linear value 23452 5B9C E 1 UNSIGNED_16 1
C01124
Sync correction width Selection list 23451 5B9B E 1 UNSIGNED_8 1
C01130
LS_RetainData: Selection Bit coded 23445 5B95 A 4 UNSIGNED_16 1
C01131
LS_RetainData: 16Bit data Linear value 23444 5B94 A 4 UNSIGNED_16 1
C01132
LS_RetainData: 32Bit data Linear value 23443 5B93 A 4 INTEGER_32 1
C01133
LS_RetainData: Bool data Selection list 23442 5B92 A 4 UNSIGNED_8 1
C01134
LS_RetainData: 16Bit data Linear value 23441 5B91 A 4 UNSIGNED_16 1
C01135
LS_RetainData: 32Bit data Linear value 23440 5B90 A 4 INTEGER_32 1
C01136
LS_RetainData: Bool data Selection list 23439 5B8F A 4 UNSIGNED_8 1
C01138
L_Transient 1-4: Function Selection list 23437 5B8D A 4 UNSIGNED_8 1
C01139
L_Transient 1-4: Pulse duration Linear value 23436 5B8C A 4 UNSIGNED_16 1000
C01140
L_Transient 5-8: Function Selection list 23435 5B8B A 4 UNSIGNED_8 1
C01141
L_Transient 5-8 pulse duration Linear value 23434 5B8A A 4 UNSIGNED_16 1000
C01150
L_PhaseIntK: Function Selection list 23425 5B81 A 2 UNSIGNED_8 1
C01151
L_PhaseIntK: Compare Linear value 23424 5B80 A 2 INTEGER_32 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
