15 Parameter reference
15.7 Table of attributes
1190
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02610 MCK: Accel./decel. times Linear value 21965 55CD A 3 UNSIGNED_32 1000
C02611
MCK: Limitations Linear value 21964 55CC A 5 INTEGER_16 100
C02652
Settings of measuring system Bit coded 21923 55A3 E 1 UNSIGNED_16 1
C02810
TP: Edge selection Selection list 21765 5505 A 7 UNSIGNED_8 1
C02811
TP: Sensor delay Linear value 21764 5504 A 7 UNSIGNED_16 1
C02812
TP: Position offset Linear value 21763 5503 A 7 INTEGER_32 10000
C02813
TP: Pos window start Linear value 21762 5502 A 3 INTEGER_32 10000
C02814
TP: Pos window end Linear value 21761 5501 A 3 INTEGER_32 10000
C02815
TP: Position source Selection list 21760 5500 A 7 UNSIGNED_8 1
C02816
TP: Signal counter Linear value 21759 54FF A 7 UNSIGNED_16 1
C02817 TP: TouchProbe position Linear value 21758 54FE A 7 INTEGER_32 10000
C02830 DIx: Debounce time Selection list 21745 54F1 A 7 UNSIGNED_8 1
C02840
CountInx: Parameter Linear value 21735 54E7 A 4 UNSIGNED_32 1
C02841
CountInx: Counter content Linear value 21734 54E6 A 2 UNSIGNED_32 1
C02842 FreqInxx: Offset Linear value 21733 54E5 A 2 INTEGER_16 100
C02843
FreqInxx: Gain Linear value 21732 54E4 A 2 INTEGER_16 100
C02844
FreqIn12: Function Selection list 21731 54E3 A 1 UNSIGNED_8 1
C02845
FreqIn12: PosIn comparison value Linear value 21730 54E2 E 1 INTEGER_32 1
C02853
PSM: Lss saturation characteristic Linear value 21722 54DA A 17 UNSIGNED_8 1
C02855
PSM: Imax Lss saturation characteristic Linear value 21720 54D8 E 1 UNSIGNED_16 10
C02859
PSM: Activate Ppp saturation char. Selection list 21716 54D4 E 1 UNSIGNED_8 1
C02864
MCTRL: Optimisations Bit coded 21711 54CF A 1 UNSIGNED_16 1
C02865
MCTRL: Special settings Bit coded 21710 54CE A 1 UNSIGNED_16 1
C02866
MCTRL: Special settings Selection list 21709 54CD A 3 UNSIGNED_8 1 CINH
C02867
Identification process Selection list 21708 54CC A 1 UNSIGNED_8 1 CINH
C02868
Setting of compatibility Bit coded 21707 54CB A 1 UNSIGNED_32 1
C02870
PLI without motion: Optimisation factor Linear value 21705 54C9 A 1 INTEGER_16 100
C02871 PLI without motion: Running time Linear value 21704 54C8 A 1 INTEGER_16 100
C02872 PLI without motion: Adaptation of time
duration
Linear value 21703 54C7 A 1 INTEGER_8 1
C02873
PLI without motion: Ident. el. rotor displ.
angle
Linear value 21702 54C6 A 1 INTEGER_16 1
C02874 PLI without motion Bit coded 21701 54C5 A 1 UNSIGNED_16 1
C02875
PLI without motion: Adaptation of ident
angle
Linear value 21700 54C4 A 1 INTEGER_8 1
C02879
Slip calculation from equivalent circuit
diagram
Bit coded 21696 54C0 A 1 UNSIGNED_16 1
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
Greyed out = display parameter (read only access)
