Lexmark CX310 Service Manual

Connector Connects to Pin no. Signal
JSP1 Smart pick drive (paper pick motor drive
assembly)
• Encoder—pins 1, 3, 5, 7, and 9
• Smart pick—pins 2, 4
• Motor—pins6, 8, 10, 12
• Input (S2) sensor—pins 13–16
1 ANODE (no wire)
2 +24 V dc M1_OUT1 (0 V dc with door open)
3 Ground (no wire)
4 +24 V dc M1_OUT2 (0 V dc with door open)
6 Ground (no wire)
7 Ground
10 +5 V dc
13 Ground (no wire)
15 +5 V dc
16 Ground
JTHM1 TPS thermistor connector 1 +1.5 V dc TPS_THERM_SNS
2 TPS_SNS_RTN, ground
JSPKR1 Speaker N/A Not testable in the field
JTPS1 Toner patch sensor 1 3 Ground (no wire)
5 Ground
JTPS2 Toner patch sensor 2 3 Ground (no wire)
5 Ground
JTRAY1 Tray present sensor 2 +3.3 V dc
3 Ground
JUSB1 Port USB connector N/A N/A
JWIRE1 USB wireless connector N/A Not testable in the field
JWT1 Waste toner detection 3 +1.5 V dc
4 Ground (no wire)
7527
Component locations
351

Lexmark CX310 Specifications

General

Print Technology	Laser
Scan Technology	CIS
Scan Resolution	Up to 600 x 600 dpi
Duplex Printing	Manual
Display	2.4-inch color LCD
Processor Speed	800 MHz
Standard Memory	256 MB
Fax Speed	33.6 Kbps
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet
Standard Paper Input	250 sheets
Scanner Type	Flatbed, ADF
Fax Resolution	300 x 300 dpi
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Copy Speed	Up to 22 cpm (black), Up to 18 cpm (color)
