Connector Connects to Pin no. Signal
JLVPS1 Low-voltage power supply 1 +5 V dc
2 Ground
3 +5 V dc
4 Ground
5 +5 V dc
6 Ground
7 +24 V dc
8 Ground
9 +24 V dc
10 Ground
11 +24 V dc
12 Ground
14 ZERO_XING_IN
16 Ground
JMIRR1 Mirror motor connector 2 +3.3 V dc MM_LOCK
4 Ground
5 +24 V dc
JOPT1 Optional—Tray(s) 2 Ground
3 Ground
5 +24 V dc
6 Ground
7 +5 V dc +5V_OPTIONS
9 Ground
10 Ground
JPH1 Printhead flat cable connector N/A Not testable in the field
JPJP1 Bin full sensor 2 3.3 V dc
3 Ground
JSC1 Smart Chip cartridge 4 Ground
7527
Component locations
350
