9 Secure the rear part of the 550‑sheet tray to the tandem tray.
10 Remove the cover under the right side of the printer.
11 Align the printer with the optional trays, and then lower it into place.
CAUTION—POTENTIAL INJURY: If the printer weight is greater than 20 kg (44 lb), then it may
require two or more people to lift it safely.
Set up, install, and configure 114
