16 Turn knob N2 counterclockwise.
17 Remove the jammed paper.
Warning—Potential Damage: To prevent damage to the printer, remove any hand accessories before
removing the jammed paper.
Note: Make sure that all paper fragments are removed.
18 Put handle N1 back into place.
19 Close door N5, and then close door N4.
20 Close door F.
21 Return handles R1 and R4 back into their original positions.
22 Close door H.
Paper jam in the booklet maker
1
Remove jammed paper in bin 2.
Note: Make sure that all paper fragments are removed.
Troubleshoot a problem 516
