Learning Basic Features
76
Basic Tasks
Description
Ref.
Command source
configuration for RS-485
communication
Configures the inverter to accept communication
signals from upper level controllers, such as PLCs or
PCs.
p.105
Motor rotation control
Configures the inverter to limit a motor‘s rotation
direction.
p.105
Automatic start-up at
power-on
Configures the inverter to start operating at power-on.
With this configuration, the inverter begins to run and
the motor accelerates as soon as power is supplied to
the inverter. To use automatic start-up configuration,
the operation command terminals at the terminal block
must be turned on.
p.107
Automatic restart after reset
of a fault trip condition
Configures the inverter to start operating when the
inverter is reset following a fault trip. In this
configuration, the inverter starts to run and the motor
accelerates as soon as the inverter is reset following a
fault trip condition.
For automatic start-up configuration to work, the
operation command terminals at the terminal block
must be turned on.
p.109
Acc/Dec time configuration
based on the Max.
Frequency
Configures the acceleration and deceleration times for
a motor based on a defined maximum frequency.
p.110
Acc/Dec time configuration
based on the frequency
reference
Configures acceleration and deceleration times for a
motor based on a defined frequency reference.
p.112
Multi-stage Acc/Dec time
configuration using the
multi-function terminal
Configures multi-stage acceleration and deceleration
times for a motor based on defined parameters for the
multi-function terminals.
p.113
Acc/Dec time transition
speed (frequency)
configuration
Enables modification of acceleration and deceleration
gradients without configuring the multi-functional
terminals.
p.114
Acc/Dec pattern
configuration
Enables modification of the acceleration and
deceleration gradient patterns. Basic patterns to
choose from include linear and S-curve patterns.
p.117
Acc/Dec stop command
Stops the current acceleration or deceleration and
controls motor operation at a constant speed. Multi-
function terminals must be configured for this
command.
p.119
Linear V/F pattern
operation
Configures the inverter to run a motor at a constant
torque. To maintain the required torque, the operating
p.120
