dot2 User Manual

If an attribute has no DMX output, the value 0 and the cell is gray displayed.

If an attribute has a DMX output, the values starts with 1 (dark green) and goes up to 255 (neon bright green).

To search for a fixture in the DMX view and mark it: Select the fixture in the fixture view and the dynamic mode goes

to the respective DMX address.

If one or more fixtures are selected in the fixtures view, the are displayed in the DMX view with a yellow frame around

it.

Parked DMX channels are displayed with a blue background.

To unpark DMX channels, open the tools window.

215
