© 2015 MA Lighting Technology GmbH - Dachdeckerstr. 16 - D-97297 Waldbüttelbrunn - Germany - www.malighting.com
dot2 User Manual
6.74. Timecode Configuration Window
The Timecode Configuration Window is located in the Setup, column Show, Timecode.
In this window, you can enable and disable incoming MIDI and SMPTE.
On the left side of the screen are the two available timecodes displayed.
MIDI
SMPTE
The green tick displays, that this timecode type is enabled.
The red prohibition sign displays, that this timecode type is disabled.
To enable or disable a timecode type, tap at the icon.
If timecode is connected, the received timecode is displayed below the timecode type.
If you have an external screen connected, the timecode is visible in the view bar below the clock time and date.
To leave the Timecode Configuration Window, tap in the title bar or press Esc . You are back in the Setup.
Encoder Bar Functions
Timecode:
To select a timecode, turn the encoder left or right.
To enable or disable a timecode, press the encoder.
6.75. Tools Window
316
