214683 386 Revision A
S
Knifeheads; refer to Every 25 Hours, page
390
NOTE: MacDon recommends keeping a record of daily
maintenance as evidence of a properly maintained
machine; however, daily maintenance records are not
required to meet normal warranty conditions.
50 Hours or Annually
S
Driveline and driveline universals; refer to
Every 50 Hours, page 391
S
Upper cross auger center support and
U-joint; refer to Every 50 Hours, page 391
S
Center draper roller bearings, 3 locations;
refer to Every 50 Hours, page 391
▲
Knife drive box lubricant (first 50 hours
only); refer to Changing Oil in Knife Drive
Box, page 461
▲
Header drive gearbox lubricant (first 50
hours only); refer to Changing Oil in
Header Drive Gearbox, page 405
100 Hours or Annually (Whichever Occurs First)
ü
Auger to pan and feed draper clearance;
refer to 5.7.1 Adjusting Auger to Pan
Clearance, page 419
ü
Draper seal; refer to 5.14.5 Adjusting Deck
Height, page 492
ü
Gearbox lubricant level; refer to Checking
Oil Level in Header Drive Gearbox, page
404
ü
Reel drive chain tension; refer to 5.16.2
Reel Drive Chain Tension, page 528
ü
Reel finger/cutterbar clearance; refer to
Adjusting Reel Clearance, page 505
ü
Knife drive belt tension; refer to 5.9.2 Knife
Drive Belts, page 462
ü
Wheel bolt torque; refer to 5.17.1 Checking
Wheel Bolt Torque, page 542
ü
Knife drive box lubricant level; refer to
Checking Knife Drive Box, page 454
ü
Knife drive box mounting bolts; refer to
Checking Mounting Bolts, page 455
S
Auger drive chain; refer to Every 100
Hours, page 393
S
Float pivots; refer to Every 100 Hours,
page 393
S
Float module auger pivots; refer to Every
100 Hours, page 393
MAINTENANCE AND SERVICING
