OPERATION
3. Remove three bolts (A), and remove deflector (B).
4. Reinstall three bolts (A).
5. Repeat for opposite side.
6. Close cutterbar doors. Refer to 3.3.3 Closing Cutterba r
Doors, page 38.
Figure 3.124: Deflector and Hardware
147910 100 Revision A
