MacDon R113 - Right-Side Operation; Left-Side Operation

OPERATION
3.13.1 Right-
Side O peration
Follow the ste
p below to steer the mower conditioner to the
right side of
the tractor.
Figure 3.5
6: Right-Side Operation
1. Move steering control lever (A) forward to p osition (B)
until the mower conditioner reaches the desired path
of travel on the right side of the tractor.
Figure
3.57: Tracto r Ste e r in g C o n tro l Lever
3.13.2
Left-Side Operation
Follo
w the step below to steer the mower conditioner to the
left s
ide of the tractor.
Fi
gure 3.58: Left-Side Operation
147910 62 Revision A
