MacDon R113 - Disengaging Locks

OPERATION
3.1.2 Disengaging Locks
1. Open the lock-
out valve (A) on each lift cylinder by
turning the ha
ndle to the vert ical position .
Figure 3.3: Lift Cylinder Lock-Out Valve
2. Move cylin
der c ontrol lever (A) forward to position (B)
to lower ma
chine.
Figure 3.4: Tractor Cylinder Control Lever
147910 32 Revision A
