OPERATION
3.8 Detaching Mower Conditioner from Tractor
3.8.1 Detaching from Drawbar
CAUTION
• To prevent accidental movement of tractor, shut off engine, engage parking brake, and remove key.
• To maintain stability, always lower the machine completely. Block mower conditioner wheels before
detaching fro m tractor.
1. Park machine on flat, level surface.
2. Lower m ower conditioner onto blocks or leave mower
conditioner raised.
NOTE:
If leaving mower conditioner in raised position,
close lift cylinder lock-out va lves.
3. Shut off engine and remove key.
4. Move remote cylinder control valve lever back and forth
to relieve stored hydraulic pressure.
If Road Friendly Transport
™
is installed:
5. Disconnect the power wires from the remote
control (A).
6. Roll up cable (B) and attach the remote control (A) to
the hitch with the magnet on the back of the remote
control box.
Figure 3.39: Remote Control
