2.3 Product Specifications
NOTE:
Specifications and design are subject to change without notice or obligation to revise previously sold units.
Table 2.1 Mower Conditioner Specifications
Components
13-Foot 16-Foot
Frame and Structure
without ET
O
1
13 ft.-4 in
. (4063 mm)
16 ft.-6 in
. (5027 mm)
Transport width
with ETO
2
8 ft.-9 in. (2743 mm)
without ETO 27 ft.-6 in. (8382 mm) 28 ft.-3 in. (8610)
Transpor
t length
with ETO 32 ft.-7
in. (8382 mm)
33 ft.-4
in. (10,160 mm)
without ETO 5440 lb. (2470 kg) 6550 lb. (2974 kg)
Estimated weig ht
with ETO 6190 lb. (2810 kg) 7300 lb. (3314 kg)
Carrie
r Pull-type
Lighting
Two red tail-lights and two amber signal/hazard lights
Carrier 15in. /31x13.5–15NHS8plyfield tires
Tire
s
ETO ST2
35/80 R16 LR E
without ETO 12 ft .-1 in. (3682 mm)
Tread width
with ETO 7 ft.-11 in. (2413 mm )
Manual storage Plastic case on mower conditioner right end backsheet
Cutterbar
Q
uantity of cutting discs 8 10
Blades per disc Two 11 degrees bevel down reversible
Disc speed 2652 rpm
Blade tip spee d range
188 mph (84.7 m/s)
Effective cutting width 156-5/8 in. (3978 mm) 194-5/8 in. (4942 mm)
Cutting height 1-1/16 in. (27 mm)
Cutting angle range
0–7 degrees below horizontal
Skid shoes Two adjustable Four adjustable
Geartrain protection Shearable d isc spindles
Deflectors
Two drum-type converging Four drum-type converging
Drives
Tractor PTO 1-3/8 in. (35 mm) dia. 21 spline, or 1-3/4 in. (44 mm) dia. 20 spline
Mechanical Gearbox and driveline
Conditioner: Roll Type
Drive 4HB b elt driven enclosed timing gearbox and driveline
1. Road Friendly Transport
™
Option
2. Without c rop dividers
