PRODUCT OVERVIEW
Components
13-Foot 16-Foot
Conditioner s
ystem
Intermeshing
rolls (steel or polyurethane)
Conditioner speed
900 rpm
Length of rolls 10 ft.–9 in. (3275 mm)
Roll diameter
Intermeshing steel bars
9 in. (229 mm) / 7 in. (179 mm) tube
Intermeshing polyurethane bars
10 in. (25 4
mm) / 8 in. (203 m m) tube
Swath width 36–114 in. (915–2896 mm)
Forming shields
Carrier mounted assembly with adjustable side deflectors
Conditi
oner: Finger Type
Drive 4HB belt driven
Condit
ioner system V-shape d tines on r ot at ing drum
Conditioner speed
896
3
rpm
Rotor length
10 ft.-9 in. (3275 mm)
Rotor diamete r
25-1
/2 in. (648 mm) / 6 in. (152 mm) tube
Swath width 36–114 in. (915–2896 mm)
Forming shields
Carrier mounted assembly with adjustable side deflectors
Gr
ound Speed
Recommended cutting
5–10 mph (8–15 km/h)
Recommended transport
20 mph (30 km/h)
Tractor Requirements
PTO power - m inimum 100 hp (74 kW ) 125 hp ( 9 3 kW)
Pressure 2000 psi (13.71 MPa)
Hydraulics
4
Controls Two double-acting / one single-acting
5
Hitch Draw bar, two-point, or quick attach
NOTE:
Tractormustbeequippedwithacab.
3. Can be set to 600 rpm by interchanging the pulleys.
4. Road Friendly Transport
™
system option uses same hydraulic circuit as hitch swing.
5. Single-acting header lift circuit is converted to double-acting when Road Friendly Transport
™
system option is
installed.
