MAINTENANCE AN D SERVICING
Taper pins are located at two places (B) on the cross shaft driveline. Torque each pin to 110 ft·lbf (150 N·m) every
25 hours until it no longer moves, and then check at the beginning of every season.
Figure 4
.187: Cross Shaft Driveline Taper Pin Locations
4.5.7 Driveline Guards
Removing Driveline Guard
WARNING
Do NOT operate the machine without the driveline guards in place and securely fastened.
DANGER
To avoid b
odily injury or death from unexpected startup of machine, always stop engine and remove key
from igni
tion before leaving operator ’s seat for any reason.
147910 201 Revision A
